bnc plug

Cable Connector

Model AC

Retrieving Price...

(Pricing valid only in the U.S.)

Add to Cart
Units in Stock Lead Times
7 Call for Lead Time
  • CE
  • IP

BNC Plug

Protective Cap: 085A35


  • Connector Style: BNC
  • Connector Style: Coaxial
  • Connection Type: Plug (male pin)
  • Temperature Range: -85 to 329 °F (-65 to +165 °C)

Specification Notes

[1] "56396"

English: SI:
Performance
Connector Style BNC BNC
Connector Style Coaxial Coaxial
Connection Type Plug (male pin) Plug (male pin)
Coupling Method (Locking) Bayonet Bayonet
Strain Relief Molded Boot Molded Boot
Environmental
Temperature Range -85 to 329 °F -65 to +165 °C
Electrical
Impedance 50 Ohm 50 Ohm
Insulation Resistance 5000 MOhm 5000 MOhm
Physical
ROHS Compliant Yes Yes
Housing Material Brass Brass
Finish Nickel Coated Nickel Coated
Size - OD .57 in 14 mm
Size - Length 1.1 in 28 mm
Weight 0.51 oz 14 gm
