| Performance |
| Number of Conductors |
4 |
4 |
|
| Cable Style |
Multi Conductor - Shielded |
Multi Conductor - Shielded |
|
| Cable Configuration |
Twisted Bundle |
Twisted Bundle |
|
| Environmental |
| Temperature Range |
-76 to +392 °F |
-60 to +200 °C |
|
| Electrical |
| Capacitance (conductor to conductor @ 70 °F (21 °C)) |
15 pF/ft |
48 pF/m |
|
| Capacitance (conductor to shield / drain @ 70 °F (21 °C)) |
24 pF/ft |
76.8 pF/m |
|
| Physical |
| Cable Jacket Diameter |
.100 in |
2.54 mm |
[1]
|
| Cable Jacket Material |
Silicone |
Silicone |
|
| Cable Jacket Color |
Blue |
Blue |
|
| Conductor Style |
Stranded - 7 Strands 40 AWG |
Stranded - 7 Strands 40 AWG |
|
| Conductor Material |
Silver Plated Copper |
Silver Plated Copper |
|
| Conductor Diameter (32 AWG) |
.01 in |
.254 mm |
[1]
|
| Insulation Material Over Conductor(s) |
Extruded PTFE |
Extruded PTFE |
|
| Shield Type Over Conductor(s) |
Braid: 90% Minimum Coverage |
Braid: 90% Minimum Coverage |
|
| Shield Material Over Conductor(s) |
Nickel Plated Wire |
Nickel Plated Wire |
|
| Bend Radius (minimum) |
1 in |
25.4 mm |
|
| Weight |
.45 oz/ft |
41.82 gm/m |
[1]
|
