Model: HT622B01

$330.00 USD
(Pricing valid in US only)

Click for lead times

High temperature, industrial, ceramic shear ICP® accel, 100 mV/g, 0.2 to 15k Hz, top exit, 2-pin conn., frequency sweep ISO 17025 accredited calibration

  • Sensitivity: (±5%) 100 mV/g (10.2 mV/(m/s²))
  • Frequency Range: (±3dB) 12 to 900000 cpm (0.2 to 15000 Hz)
  • Sensing Element: Ceramic
  • Measurement Range: ±50 g (±490 m/s²)
  • Weight: 3.3 oz (94 gm)

Add this product to my product comparison
Compare selected models ()

Sensitivity (±5 %)100 mV/g10.2 mV/(m/s²)[1]
Measurement Range±50 g±490 m/s²
Frequency Range (±5 %)35 to 360000 cpm0.58 to 6000 Hz[3]
Frequency Range (±10 %)25 to 600000 cpm0.42 to 10000 Hz
Frequency Range (±3 dB)12 to 900000 cpm0.2 to 15000 Hz
Resonant Frequency1800 kcpm30 kHz[4]
Broadband Resolution (1 to 10000 Hz)150 µg1472 µm/sec2[4]
Non-Linearity±1 %±1 %[2]
Transverse Sensitivity≤5 %≤5 %
Overload Limit (Shock)5000 g pk49050 m/s² pk
Temperature Range-65 to +325 °F-54 to +163 °C
Temperature ResponseSee Graph %/°FSee Graph %/°F[4]
Enclosure RatingIP68IP68
Settling Time (within 1% of bias)≤5.0 sec≤5.0 sec
Discharge Time Constant≥0.8 sec≥0.8 sec
Excitation Voltage18 to 28 VDC18 to 28 VDC
Constant Current Excitation2 to 10 mA2 to 10 mA
Output Impedance<700 Ohm<700 Ohm
Output Bias Voltage8 to 15 VDC8 to 15 VDC
Spectral Noise (10 Hz)12 µg/√Hz118 (µm/sec2)/√Hz[4]
Spectral Noise (100 Hz)3.2 µg/√Hz31.4 (µm/sec2)/√Hz[4]
Spectral Noise (1 kHz)1.2 µg/√Hz11.8 (µm/sec2)/√Hz[4]
Electrical ProtectionRFI/ESDRFI/ESD
Electrical Isolation>100000000 Ohm>100000000 Ohm
Size - Hex7.8 in22 mm
Size - Height2.06 in52.3 mm
Weight3.3 oz94 gm
Mounting Thread1/4-28 FemaleNo Metric Equivalent[5]
Mounting Torque2 to 5 ft-lb2.7 to 6.8 Nm
Sensing ElementCeramicCeramic
Sensing GeometryShearShear
Housing MaterialStainless SteelStainless Steel
SealingWelded HermeticWelded Hermetic
Electrical Connector2-Pin MIL-C-50152-Pin MIL-C-5015
Electrical Connection PositionTopTop

All specifications are at room temperature unless otherwise specified.


Product Notes
[1] Conversion Factor 1g = 9.81 m/s².
[2] Zero-based, least-squares, straight line method.
[3] The high frequency tolerance is accurate within ±10% of the specified frequency.
[4] Typical.
[5] 1/4-28 has no equivalent in S.I. units.
[6] See PCB Declaration of Conformance PS023 or PS061 for details.
ICS-1NIST-traceable single-axis amplitude response calibration from 600 cpm (10 Hz) to upper 5% frequency(1)
081A40Mounting Stud(1)
Optional Versions:
(EX) Hazardous Area Approval- contact factory for specific approvals
(M) Metric Mount
    M081A61Mounting Stud(1)
