differential charge output pressure sensor with uht-12™ element, 15.5 pc/psi, +662 f hazardous approved atex, csa

HIGH TEMPERATURE PRESSURE SENSOR

Model 176B04

Retrieving Price...

(Pricing valid only in the U.S.)

Units in Stock	Lead Times
More on the way	Call for Lead Time

Differential charge output pressure sensor with UHT-12™ element, 15.5 pC/psi, +662 F Hazardous approved ATEX, CSA

Measurement Range: 300 psi (20.7 bar)
Sensing Element: UHT-12™
Temperature Range: -65 to 662 °F (-54 to 350 °C)
Electrical Connector: 2-Pin
Weight: 3.9 oz (122 g)

Specification Notes

[1] Zero-based, least-squares, straight line method.
[2] Typical.
[3] Low frequency response is determined by external signal conditioning electronics.
[4] Upper frequency response is calculated from Resonant Frequency.
[2] Typical.
[5] Maximum.
[2] Typical.
[6] See PCB Declaration of Conformance PS058 for details.

	English:	SI:
Performance
Sensitivity (±20 %)	15.5 pC/psi	225 pC/bar
Sensitivity (±20 %)	15.5 pC/psi	225 pC/bar
Measurement Range	300 psi	20.7 bar
Maximum Pressure (Total)	1450 psi	100 bar
Resonant Frequency	≥50 kHz	≥50 kHz
Transverse Resonance	10 kHz	10 kHz	[2]
Frequency Response	10 kHz	10 kHz	[3] [4]
Non-Linearity	≤1 % FS	≤1 % FS	[1]
Environmental
Acceleration Sensitivity	0.01 psi/g	.00069 bar/g	[5]
Acceleration Sensitivity	.005 psi/g	.00035 bar/g	[2]
Temperature Range (Continuous)	-65 to 662 °F	-54 to 350 °C
Temperature Range (Intermittent)	-320 to 752 °F	-196 to 400 °C
Temperature Response	See Graph	See Graph	[2]
Hazardous Area Approval	See Manual	See Manual
Radiation Exposure Limit (Integrated Neutron Flux)	1E10 N/cm²	1E10 N/cm²
Radiation Exposure Limit (Integrated Gamma Flux)	1E8 rad	1E8 rad
Electrical
Output Polarity	Differential	Differential
Capacitance	45 pF	45 pF	[2]
Resistance(Pin-Pin) (Room Temp)	≥1000000000 Ohm	≥1000000000 Ohm
Resistance(Pin-Case) (Room Temp)	≥1000000000 Ohm	≥1000000000 Ohm
Resistance(Pin-Pin) (572°F/300°C)	≥10000000 Ohm	≥10000000 Ohm
Resistance(Pin-Case) (572°F/300°C)	≥10000000 Ohm	≥10000000 Ohm
Physical
Sensing Element	UHT-12™	UHT-12™
Sensing Geometry	Compression	Compression
Housing Material	Nickel Alloy	Nickel Alloy
Sealing	Welded Hermetic	Welded Hermetic
Electrical Connector	2-Pin	2-Pin
Weight	3.9 oz	122 g
