miniature instrumented impulse hammer, 0 to 50 lbf

ICP® Impact Hammer

Model 086E80

Retrieving Price...

(Pricing valid only in the U.S.)

Add to Cart
Units in Stock Lead Times
More on the way Lead Time for 1-3 is 10 Wks
  • CE
  • IP

Miniature Instrumented Impulse Hammer, 0 to 50 lbf

  • Sensitivity: (±20%)100 mV/lbf (22.5 mV/N)
  • Measurement Range: 50 lbf pk (222 N pk)
  • Hammer Mass: 0.17 oz (4.8 gm)

Specification Notes

[1] Typical.
[2] Steel tip with no extender mass.
[1] Typical.
[3] With plastic handle attached.
[4] With aluminum handle attached.
[5] See PCB Declaration of Conformance PS136 for details.

English: SI:
Performance
Sensitivity (±20 %) 100 mV/lbf 22.5 mV/N [2]
Measurement Range 50 lbf pk 222 N pk
Resonant Frequency ≥100 kHz ≥100 kHz
Non-Linearity ≤1 % ≤1 % [1]
Electrical
Excitation Voltage 20 to 30 VDC 20 to 30 VDC
Constant Current Excitation 2 to 20 mA 2 to 20 mA
Output Impedance <100 Ohm <100 Ohm
Output Bias Voltage 8 to 14 VDC 8 to 14 VDC
Discharge Time Constant ≥100 sec ≥100 sec [1]
Physical
Sensing Element Quartz Quartz
Sealing Epoxy Epoxy
Hammer Mass 0.17 oz 4.8 gm [3]
Head Diameter 0.25 in 6.3 mm
Tip Diameter 0.10 in 2.5 mm
Hammer Length 4.2 in 107 mm [3]
Electrical Connection Position Side Side
Extender Mass Weight 0.044 oz 1.25 gm
Electrical Connector 5-44 Coaxial 5-44 Coaxial [4]

* All specifications are at room temperature unless otherwise specified.

Accessories
Supplied
001A20 Black plastic kudle pack, 8.5" x 6" x 2.5 " 1
018G10 Miniature, lightweight, black coaxial cable, vinyl insulation jacket, 10-ft, 5-44 plug to 10-32 plug 1
080A109 Petro Wax, one square, 1" x 1" x 0.25" 1
084A13 Extender mass (for Model 086E80) 1
084A17 Aluminum handle, 5-44 conn. (for Model 086E80) 1
HCS-2 Calibration of Series 086B to 086D instrumented hammers only 1
084A14 Plastic handle assembly (for Model 086E80) 2
084A28 Vinyl impact cap, red (for Models 086) 3
