| Performance |
| Number of Conductors |
3 |
3 |
|
| Cable Style |
Multi Conductor - Shielded |
Multi Conductor - Shielded |
|
| Cable Configuration |
Twisted Bundle |
Twisted Bundle |
|
| Environmental |
| Temperature Range |
-65 to +250 °F |
-54 to +121 °C |
|
| Electrical |
| Impedance |
73 Ohm |
73 Ohm |
[1]
|
| Capacitance (conductor to conductor @ 70 °F (21 °C)) |
20 pF/ft |
66 pF/m |
|
| Physical |
| Cable Jacket Diameter (±.005 in) |
0.160 in |
4.06 mm |
[1]
|
| Cable Jacket Material |
Polyurethane |
Polyurethane |
|
| Cable Jacket Color |
Black |
Black |
|
| Conductor Style |
Stranded - 19 Strands 40 AWG |
Stranded - 19 Strands 40 AWG |
|
| Conductor Material |
Tin Plated Copper |
Tin Plated Copper |
|
| Conductor Diameter (28 AWG) |
0.013 in |
0.330 mm |
[1]
|
| Shield Type Over Bundle |
Braid: 94% Minimum Coverage |
Braid: 94% Minimum Coverage |
|
| Shield Material Over Bundle |
Tin Plated Copper |
Tin Plated Copper |
|
| Filler Material |
Synthetic FFP |
Synthetic FFP |
|
| Bend Radius (minimum) |
1.60 in |
40.64 mm |
|
| Weight |
0.28 oz/ft |
26.04 gm/m |
[1]
|
