end of life - existing stock only accelerometer, iepe, 10 mv/g, ±500 g, -67°f to +302°f, isolated, thru-hole mount, side connector, 14 grams

RING SHEAR ISOTRON ACCEL

Model 7251HT-10

  • IP

END OF LIFE - EXISTING STOCK ONLY Accelerometer, IEPE, 10 mV/g, ±500 g, -67°F to +302°F, isolated, thru-hole mount, side connector, 14 grams

    Specification Notes

    English: SI:
    General
    Output type Voltage (IEPE) Voltage (IEPE)
    Sensitivity 10 mV/g 1.02 mV/(m/sec2)
    Max Measurement Range 500 g pk 4905 m/sec2 pk
    Max Frequency (±5%) 10000 Hz 10000 Hz
    Weight 0.494 oz 14 gm
    Number of Axis 1 1
    Replacement (-R) No No

    * All specifications are at room temperature unless otherwise specified.

    Accessories
    3061A-120 https://buy.endevco.com/cables/3061a-cable 1

    Product Documents

    Product Downloads

    Datasheet

    Datasheet
