Model : 046 | Cable

Call for lead time
pvc cable, 32-conductor, twisted pairs, overall shielded
Add to Cart for Quote

PVC cable, 32-conductor, twisted pairs, overall shielded

  • Cable Style: Multi Conductor - Shielded
  • Number of Conductors: 32
  • Cable Jacket Material: PVC
  • Temperature Range: -40 to +221 °F ( -40 to +105 °C)
English: SI:
Performance
Number of Conductors 32 32
Cable Style Multi Conductor - Shielded Multi Conductor - Shielded
Cable Configuration Twisted Pair Twisted Pair
Environmental
Temperature Range -40 to +221 °F -40 to +105 °C
Physical
Cable Jacket Diameter 0.70 in 17.8 mm [ 1]
Cable Jacket Material PVC PVC
Cable Jacket Color Black Black
Conductor Style Stranded - 7 Strands 28 AWG Stranded - 7 Strands 28 AWG
Conductor Material Tin Plated Copper Tin Plated Copper
Conductor Diameter (20 AWG) 0.038 in 0.965 mm [ 1]
Insulation Material Over Conductor(s) PVC PVC
Shield Type Over Bundle Foil Foil
Shield Material Over Bundle Aluminum / Mylar Aluminum / Mylar
Drain Wire Material Tin Plated Copper Tin Plated Copper
Drain Wire Diameter 0.030 in 0.762 mm [ 1]
Bend Radius (minimum) 7 in 178 mm
Weight 4.0 oz/ft 368 gm/m [ 1]
* All specifications are at room temperature unless otherwise specified
.




Specification Notes


[ 1] Typical.
