Rotary Transformer

Rotary transformer torque sensors offer high accuracies and RPM ratings. They are designed with an advanced transformer, shaft and housing to provide enhanced durability in rugged industrial applications. Rotating shaft torque sensors are available in a wide range of configurations. For Rotary Transformer products with a higher temperature range, please contact PCB Load & Torque, Inc. at 866-684-7107 or ltinfo@pcbloadtorque.com.

Compare selected models ()
[ clear compare ]
Mouse Over Image for Product Description.

Model 4115K-04A

  • (Full Scale Capacity)500 in-lb
  • (Full Scale Capacity)55 Nm
  • (output at rated capacity)(±15%)2.5 mV/V
  • (output at rated capacity)(±15%)2.5 mV/V
  • <=0.05 % FS
  • <=
  • Flange w/ Splined Shaft
  • Flange w/ Splined Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart

Model 4115K-06A

  • (Full Scale Capacity)1000 in-lb
  • (Full Scale Capacity)115 Nm
  • (output at rated capacity)(±15%)2.5 mV/V
  • (output at rated capacity)(±15%)2.5 mV/V
  • <=0.05 % FS
  • <=
  • Flange w/ Splined Shaft
  • Flange w/ Splined Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart

Model 4115K-08A

  • (Full Scale Capacity)2000 in-lb
  • (Full Scale Capacity)225 Nm
  • (output at rated capacity)(±15%)2.5 mV/V
  • (output at rated capacity)(±15%)2.5 mV/V
  • <=0.05 % FS
  • <=
  • Flange w/ Splined Shaft
  • Flange w/ Splined Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart

Model 4115K-11A

  • (Full Scale Capacity)5000 in-lb
  • (Full Scale Capacity)565 Nm
  • (output at rated capacity)(±15%)2.5 mV/V
  • (output at rated capacity)(±15%)2.5 mV/V
  • <=0.05 % FS
  • <=
  • Flange w/ Splined Shaft
  • Flange w/ Splined Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart

Model 4105-01A

  • (Full Scale Capacity)2000 in-lb
  • (Full Scale Capacity)226 Nm
  • (output at rated capacity)2.5 mV/V
  • (output at rated capacity)2.5 mV/V
  • <=0.05 % FS
  • <=
  • 1.50 in Dia. Keyed Shaft
  • 38.1 mm Dia. Keyed Shaft
  • 12000 RPM
  • 12000 RPM
Add to cart for quote
 Add to Cart

Model 4105-02A

  • (Full Scale Capacity)5000 in-lb
  • (Full Scale Capacity)565 Nm
  • (output at rated capacity)2.5 mV/V
  • (output at rated capacity)2.5 mV/V
  • <=0.05 % FS
  • <=
  • 1.50 in Dia. Keyed Shaft
  • 38.1 mm Dia. Keyed Shaft
  • 12000 RPM
  • 12000 RPM
Add to cart for quote
 Add to Cart

Model 4105-03A

  • (Full Scale Capacity)10000 in-lb
  • (Full Scale Capacity)1130 Nm
  • (output at rated capacity)2.5 mV/V
  • (output at rated capacity)2.5 mV/V
  • <=0.05 % FS
  • <=
  • 1.50 in Dia. Keyed Shaft
  • 38.1 mm Dia. Keyed Shaft
  • 12000 RPM
  • 12000 RPM
Add to cart for quote
 Add to Cart

Model 4104-01A

  • (Full Scale Capacity)500 in-lb
  • (Full Scale Capacity)56.5 Nm
  • (output at rated capacity)(±)2.5 mV/V
  • (output at rated capacity)(±)2.5 mV/V
  • <=0.05 % FS
  • <=
  • 1.00 in Dia. Keyed Shaft
  • 25.4 mm Dia. Keyed Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart

Model 4104-02A

  • (Full Scale Capacity)1000 in-lb
  • (Full Scale Capacity)113 Nm
  • (output at rated capacity)(±)2.5 mV/V
  • (output at rated capacity)(±)2.5 mV/V
  • <=0.05 % FS
  • <=
  • 1.00 in Dia. Keyed Shaft
  • 25.4 mm Dia. Keyed Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart

Model 4104-03A

  • (Full Scale Capacity)2000 in-lb
  • (Full Scale Capacity)226 Nm
  • (output at rated capacity)(±)2.5 mV/V
  • (output at rated capacity)(±)2.5 mV/V
  • <=0.05 % FS
  • <=
  • 1.00 in Dia. Keyed Shaft
  • 25.4 mm Dia. Keyed Shaft
  • 15000 RPM
  • 15000 RPM
Add to cart for quote
 Add to Cart
