Name: Model 608A11
Brand: PCB
SKU: 608A11
Availability: BackOrder

platinum stock products; low-cost, general purpose, industrial ceramic shear icp® accel, 100 mv/g, 0.5 to 10k hz, top exit, 10-ft integral cable, single point iso 17025 accredited calibration

ACCELEROMETER

Model 608A11

Add to Quote

Configure

Platinum Stock Products; Low-cost, general purpose, industrial ceramic shear ICP® accel, 100 mV/g, 0.5 to 10k Hz, top exit, 10-ft integral cable, single point ISO 17025 accredited calibration

Low-cost industrial accelerometer with integral 10 ft. cable to blunt termination, 100 mV/g, general purpose, submersible, ceramic shear ICP®, 0.5 to 10k Hz, top exit.

Additional configurations:

Specification Notes

[1] Conversion Factor 1g = 9.81 m/s².
[2] Zero-based, least-squares, straight line method.
[3] Typical.
[4] Twisted shielded pair.
[5] 1/4-28 has no equivalent in S.I. units.
[6] See PCB Declaration of Conformance PS023 or PS060 for details.

	English:	SI:
Performance
Sensitivity (±15 %)	100 mV/g	10.2 mV/(m/s²)	[1]
Measurement Range	±50 g	±490 m/s²
Frequency Range (±3 dB)	30 to 600000 cpm	0.5 to 10000 Hz
Resonant Frequency	1320 kcpm	22 kHz	[3]
Broadband Resolution (1)	350 µg	3434 µm/sec²	[3]
Non-Linearity	±1 %	±1 %	[2]
Transverse Sensitivity	≤7 %	≤7 %
Environmental
Overload Limit (Shock)	5000 g pk	49050 m/s² pk
Temperature Range	-65 to +250 °F	-54 to +121 °C
Temperature Response	See Graph %/°F	See Graph %/°F	[3]
Enclosure Rating	IP68	IP68
Electrical
Settling Time (within 1% of bias)	≤2.0 sec	≤2.0 sec
Discharge Time Constant	≥0.3 sec	≥0.3 sec
Excitation Voltage	18 to 28 VDC	18 to 28 VDC
Constant Current Excitation	2 to 20 mA	2 to 20 mA
Output Impedance	<150 Ohm	<150 Ohm
Output Bias Voltage	8 to 12 VDC	8 to 12 VDC
Spectral Noise (10 Hz)	8 µg/√Hz	78.5 (µm/sec²)/√Hz	[3]
Spectral Noise (100 Hz)	5 µg/√Hz	49.1 (µm/sec²)/√Hz	[3]
Spectral Noise (1 kHz)	4 µg/√Hz	39.2 (µm/sec²)/√Hz	[3]
Electrical Isolation (Case)	>100000000 Ohm	>100000000 Ohm
Physical
Size - Hex	9/16 in	14 mm
Size - Height	2.5 in	64 mm
Weight (with cable)	3.5 oz	99.3 gm
Mounting	Stud	Stud
Mounting Thread	1/4-28 Female	1/4-28 Female	[5]
Mounting Torque	2 to 5 ft-lb	2.7 to 6.8 Nm
Sensing Element	Ceramic	Ceramic
Sensing Geometry	Shear	Shear
Housing Material	Stainless Steel	Stainless Steel
Sealing	Molded	Molded
Electrical Connector	Molded Integral Cable	Molded Integral Cable
Electrical Connection Position	Top	Top
Cable Length	10 ft	3 m
Cable Type	Polyurethane	Polyurethane	[4]

* All specifications are at room temperature unless otherwise specified.

Accessories


Supplied
081A40	Mounting stud, 1/4-28 x 0.438" long stainless steel screw with hex socket and brass tip	1
ICS-2	Calibration of industrial accel., single-point, 100 Hz reference sensitivity	1

Optional Versions

(EX) Hazardous Area Approval- contact factory for specific approvals

	English	SI
Hazardous Area Approval	EEx nL IIC T4, -40 ° C ≤ Ta ≤ 121 ° C, II 1 G
Hazardous Area Approval	EEx nL IIC T4, -40 ° C ≤ Ta ≤ 121 ° C, II 1 G
Hazardous Area Approval	Cl I, Div I, Groups A, B, C, D; Cl II, Div I, Groups E, F, G; Cl III, Div I
Hazardous Area Approval	Cl I, Div I, Groups A, B, C, D; Cl II, Div I, Groups E, F, G; Cl III, Div I
Hazardous Area Approval	Cl I, Div 2, Groups A, B, C, D; ExnL IIC T4, AExnA IIC T4
Hazardous Area Approval	Cl I, Div 2, Groups A, B, C, D; ExnL IIC T4, AExnA IIC T4
Hazardous Area Approval	Ex ia IIC T4, AExia IIC, T4
Hazardous Area Approval	Ex ia IIC T4, AExia IIC, T4

(LB) Low Bias Voltage

	English	SI
Output Bias Voltage	4.8 to 6.5
Excitation Voltage	12 to 28
Measurement Range	±10	±98

(M) Metric Mount

Accessories:
Supplied	M081A61	Mounting Stud	1

(TO) Temperature Output

	English	SI
Electrical Connector	Molded Integral Cable
Temperature Scale Factor	5.56 mV/°F + 32	+10 mV/°C
Electrical Connections	Acceleration Output
Electrical Connections	Ground
Temperature Output Range	+36 to +250 °F	+2 to +121 °C
Electrical Connector	Molded Integral Cable
Electrical Connections	Temperature Output
